Terminal splits: many sessions, one window

Agents run long — fifteen minutes, half an hour — and in that time you want to do other work in the same project. If the app gives you one terminal per window, your options are opening another window and re-arranging your screen, or standing by. Terminal splits solve it by declining to wait: the workspace splits into panes running side by side inside one window, each pane its own session. This post reads the feature from the code side — what a split actually is in the runtime, how the layout survives a restart, and why the activation order of a pane was worth a benchmark.

TL;DR:

• A split is not a UI drawing effect: it is a runtime operation — a new leaf in the tab, wired to its own PTY for the new session.
• Each pane can receive its own command and env at split time — two panes in one tab are not two copies of the same session.
• The post-split layout is written into the durable layout tree, so splits survive snapshot rebuilds — with a dedicated test guarding that behavior.
• The order — activating a split before inherited CWD resolution — is the subject of a dedicated e2e benchmark in commit #17601.

One session per window, and the waiting is real

Consider the common rhythm of working with an agent: you watch the main session run while needing a side terminal for something quick — checking logs, running a git command, peeking at a file. With one window per session, the sequence is: pause or shrink the main session, open a new terminal, lose the context on screen, do the side task, come back. No single step is expensive; the cost is the repetition, several times a day:

one window — one session — interleaving means serial switching

  running session A (long) and side task B (short)

  serial:   [A runs ............] [pause A] [B] [reopen A] [A runs ....]
  split:    ┌────────────────────────┬──────────────┐
            │ A keeps running        │ B, as needed │
            └────────────────────────┴──────────────┘

Source: conceptual diagram of the situation terminal splits exist to solve, drawn while writing this post, retrieved 2026-09-08.

Worktree isolation — covered in real parallelism through worktree isolation — solves multiple agents fighting over files. Terminal splits solve a layer below that: several sessions inside one working space, when you actively want two views at once. The two mechanisms stack; neither replaces the other.

A split is a runtime operation, not a UI sketch

The most interesting part of reading the code: the split exists at the runtime layer, before any UI. The OrcaRuntimeWithSplitTerminal class in src/main/runtime/orca-runtime-split-terminal.ts provides a single method for it:

async splitTerminal(handle, opts: {
  direction?: 'horizontal' | 'vertical'
  command?: string
  env?: Record<string, string>
  activate?: boolean
  ...
}): Promise<RuntimeTerminalSplit>

Source: the splitTerminal signature in src/main/runtime/orca-runtime-split-terminal.ts, wakii-dev/wakii repo (fork of orca), retrieved 2026-09-08.

The signature itself carries three design decisions. One: the split takes the original session’s handle and returns a new one — the new session is a first-class entity with its own PTY via splitPtyBackedTerminal, not a shared stream with the originating pane. Two: direction is the caller’s choice (default horizontal), not a hard-coded app decision. Three — the part least visible in a UI feature: each new pane can receive its own command and env. Two panes in one tab can run two different commands in two different environments; they share the window, not the session.

The split layout survives a restart

Where such features usually break is a place nobody looks: closing the app and opening it again. A split that only updates the live session snapshot would vanish once the app rebuilds the layout from the durable snapshot. A commit in the repo describes exactly this case, right in the explanatory comment:

// Why: a headless ("Orca server") split only updated the live session
// snapshot, never the persisted workspace-session layout, so a later
// snapshot rebuild re-derived from the stale single-leaf layout and
// collapsed the split. This builds the durable post-split layout so the
// split survives rebuilds.

Source: comment in src/main/runtime/headless-terminal-split-layout.ts, wakii-dev/wakii repo, retrieved 2026-09-08.

In other words, after a split, the new layout tree is written into the durable TerminalLayoutSnapshot — a later rebuild restores the split panes instead of collapsing back to a single leaf. The behavior has a guard: headless-terminal-split-layout.test.ts sits next to the runtime file, and persistence-split-pane-incarnation.test.ts watches one level up, in src/main/. For a feature users judge by “my screen tomorrow looks like it did today”, this is the code that decides the experience — even though none of it ever shows on screen.

Even the activation order got a benchmark

Commit #17601 — “Activate terminal splits before inherited CWD resolution” — is the commit that brought splits into the v1.4.198 release tag, and its content is more surprising than the title:

$ git -C <orca-repo> show c558d7e083 --stat --format=''
.../terminal-split-activation-latency-artifact.ts    |  53 ++
.../terminal-split-activation-latency-main-probe.ts | 193 +++++
.../e2e/terminal-split-activation-latency.spec.ts   | 730 ++++++++++++++
43 files changed, 4955 insertions(+), 419 deletions(-)

Source: git show c558d7e083 --stat, orca repo, retrieved 2026-09-08.

The problem being solved: a new split must be activated (focused, ready for input) before the inherited CWD is resolved and published — with the order flipped, the new pane could pick up directory context from an uncommitted state. The commit does not just reorder; it ships a benchmark suite measuring split activation latency across phases, with a 730-line e2e spec and artifacts recorded under schema-v2. For a small UI interaction, that is unusual discipline — and it says something about where splits live in the architecture: not a drawn-on trait, but a runtime operation whose timing has to be kept exact.

The limits deserve plain speech too. Splits share a window and a tab — they do not substitute for isolation: keeping two agents off each other’s files still takes separate worktrees (see real parallelism through worktree isolation). And the benchmark part of #17601 is developer infrastructure — users never see those numbers, only the consequence: the new pane appears with the right context and does not jump directories.

To see it yourself: open Wakii, give an agent a long task, split the terminal to do side work in the same tab, then close and reopen the app to check the layout survived. Setup and first steps live on the getting started page; how the system layers file isolation and multi-session work is in real parallelism through worktree isolation.
