Running sessions side by side: split panes and per-worktree ports

One agent at work, and the screen has room to spare. Three agents in parallel — three worktrees, three terminals, three open diffs — is when the screen runs out and the real questions start: how do you watch them work side by side, does this worktree’s dev server fight that worktree’s for a port, and how do you take the seat back when one agent finishes. This post covers all three: splitting the screen, separating ports, and cleaning up.

TL;DR:

Every session is bound to a worktree — one folder per agent, nobody fights over files.
Drag a tab to a pane edge to split; splits nest several levels deep; the layout is remembered per worktree.
Dev servers run inside each worktree’s own terminal, so ports don’t collide; remote servers forward through the Ports tab.
orca terminal list|create|split|switch|close drive sessions from the CLI; orca worktree ps is the live overview.
A worktree with no active work should be closed — each one keeps its own file watchers alive.

A session is a worktree: one folder per agent

The unit of parallelism in Wakii is not “a tab” — it is a worktree. Each agent gets a worktree, meaning its own working directory of one shared repository:

repo wakii-site — one shared .git, several working directories
├── ~/orca/workspaces/wakii-site/sf-2-blog-skills  → agent writing skills posts
├── ~/orca/workspaces/wakii-site/sf-4-blog-guides  → agent writing guide posts
└── ~/orca/workspaces/wakii-site/sf-5-blog-arch    → agent writing arch posts

Source: real worktree list from orca worktree ps on the machine this post was written on, retrieved 2026-09-08 — three sub-features of one story running in parallel.

No agent touches another’s files: one folder means one branch, one index, one server. Why one worktree per branch is a safe unit of separation is what the parallel worktrees isolation post proved by experiment — this post assumes you already run several worktrees and handles the watching part.

Watching several agents at once: drag a tab to an edge to split

The screen-splitting move is drag and drop, and the docs describe exactly two directions:

“Drag a tab to the edge of a pane to create a split: Right edge — splits left/right (horizontal split). Bottom edge — splits top/bottom (vertical split).”

And splits nest, in the docs’ own example:

“Splits nest. You can have an agent terminal on the left, a diff view on the top-right, and a browser tab on the bottom-right — all at once.”

Source: the “Tabs, panes & split layouts” docs, retrieved 2026-09-08.

Two details keep a layout alive for you. First, pinned boundaries: “Pane boundaries stay where you put them” — resizing the window doesn’t shuffle the layout, and boundary positions are saved per worktree. Second, each worktree owns its layout entirely — the docs put it this way:

“Each worktree owns its own tab layout. Switching worktrees swaps the entire pane tree — your browser tab, terminal, and diff reappear exactly as you left them.”

Source: the “Tabs, panes & split layouts” docs, Pinned boundaries and Tab groups across worktrees sections, retrieved 2026-09-08.

Moving between tabs needs no mouse:

Action	macOS	Linux / Windows
Next / previous tab	`Cmd+Shift+]` / `Cmd+Shift+[`	`Ctrl+Shift+]` / `Ctrl+Shift+[`
Next / previous tab (same type)	`Cmd+Option+]` / `Cmd+Option+[`	`Ctrl+Alt+]` / `Ctrl+Alt+[`

Source: default shortcuts for new installs, the “Tabs, panes & split layouts” docs, retrieved 2026-09-08.

One dev port per worktree: servers step aside, never fight

Three worktrees usually means three dev servers running at once. They don’t collide because each server runs in the terminal of its own worktree — that is, in its own folder. Common dev servers (Vite, Astro, Next) pick the next port when the default one is taken, so the real-world picture always comes out like this:

worktree sf-2: astro dev  → port 4321
worktree sf-4: astro dev  → 4321 occupied → 4322
worktree sf-5: astro dev  → 4322 occupied → 4323

A diagram of the common “port taken, pick the next one” behavior of dev servers — open the URL printed by the server in that worktree’s terminal.

The thing to remember: the preview you open belongs to the worktree you opened it from — the URL is printed right in its terminal. A worktree on a remote machine adds one layer: the Ports tab (Cmd+Shift+I) detects listening ports on the host and forwards them to your machine — the details have their own post, SSH worktrees.

Driving sessions from the CLI: five terminal commands and one overview

Keyboard splitting is half the story; the other half is the CLI, which you can script. Five terminal commands from orca --help:

terminal list       List live Orca-managed terminals
terminal create     Create a terminal session in a worktree
terminal split      Split an existing terminal pane
terminal switch     Bring a terminal tab to the foreground
terminal close      Close one terminal, its whole tab with --tab, or all in a worktree

Source: excerpt from orca --help, retrieved 2026-09-08.

And when you want the big picture of which worktrees are alive on this machine — which have running terminals, which branch they’re on — that is orca worktree ps:

$ orca worktree ps --limit 3          # (trimmed: preview column removed)
wakii-site refs/heads/wakii-dev/sf-2-blog-skills  host=local  live:1  pty:yes  unread:yes
~/orca/workspaces/wakii-site/sf-2-blog-skills
wakii-site refs/heads/wakii-dev/sf-4-blog-guides  host=local  live:1  pty:yes  unread:yes
~/orca/workspaces/wakii-site/sf-4-blog-guides

scope: local
truncated: showing 3 of 11

Source: orca worktree ps --limit 3, run for real on the machine this post was written on, retrieved 2026-09-08 — preview column and one worktree cut.

One line per worktree: branch, host, number of live terminals (live:1), whether a pty is attached. This is the “what is actually running on this machine” command — run it before deciding what to close. The full lifecycle of create → ship → reclaim is walked through step by step in the worktree workflow guide.

Cleaning up: close finished tabs, reclaim finished worktrees

Deep split layouts are the app’s biggest memory consumers, the docs say so right in the performance section:

“Close worktrees you’re not actively using. Each worktree keeps file watchers alive. Split layouts with many browser tabs are the biggest RAM users — close browsers you don’t need.”

Source: the Troubleshooting & FAQ docs, Performance & memory section, retrieved 2026-09-08.

A sensible order: close browser tabs you no longer read first, then terminals — orca terminal close with --tab closes the whole tab, without the flag it closes a single terminal. Worktrees come last: a sub-feature that has merged, its branch back on the destination, has no more use for its file watchers. A machine that stops feeling sluggish after a parallel session usually owes that to these two steps, not to restarting the app.

Setting the app up from scratch — first repo, first terminal — is on the getting started page.

Open three worktrees of your project, drag tabs right and down, start three dev servers at once — then watch which number the second port lands on.
